Ferraz Shawmut CRN400 Fuse

Product Description

The Ferraz Shawmut CRN400 is a Class H low voltage fuse suitable for AC systems. It operates at a voltage of 250V AC and has a current rating of 400A. This fuse features a short circuit interrupting rating of 10kA at 250V. It complies with the Canadian Electrical Code and utilizes blade-style terminals for clip mounting.

• Class H fuse rated for 250V AC
• 400A current rating with a 10kA interrupting capacity
• Designed for easy clip mounting with blade terminals

Product Highlights

This fuse is essential for safety in electrical systems, ensuring reliable operation and compliance with regulatory standards.

Product Information

Standard Information

• Brand: Ferraz Shawmut
• MPN: CRN400

Technical Specifications

• Fuse Class: Class H
• Voltage Rating: 250 VAC
• Amperage Rating: 400 A
• AIC Rating: 10 kA@250V
• Mounting Type: Clip
• Standards: CSA Certified
• Connection/Terminal Type: Blade
• Body/Insulating Material: Paper
• Product Diameter: 2.06 inches
• Product Length: 8.63 inches
• Weight: 1.45 lbs
• Frequency: 50/60 Hz
• ROHS Compliant: Yes
• AC or DC: AC
