Ferraz Shawmut A6D200R Fuse

Product Description

The Ferraz Shawmut A6D200R is a time-delay Class RK1 fuse. This fuse provides IEC Type 2 no damage protection to mains, feeders, and branch circuits, supplying both motor and non-motor loads. It is designed to open quickly under extreme fault conditions to protect circuit components from damage. The time-delay feature allows for handling motor in-rush currents effectively. It is suitable for replacing older 600V Class H, K, or RK5 fuses.

• Time-delay characteristic suitable for in-rush currents.
• Short circuit protection to safeguard circuit components.
• Compatible with both AC and DC applications.

Product Highlights

The A6D200R fuse is designed for optimal performance in various electrical applications, ensuring reliability and safety.

Product Information

Standard Information

• Brand: Ferraz Shawmut
• MPN: A6D200R

Technical Specifications

• Rated Voltage AC UL: 600 V
• Rated Voltage DC UL: 600 V
• Voltage: 600 VAC/VDC
• Ampere Rating: 200 A
• Fuse Class: Class RK1
• Speed/Characteristic: Time Delay
• Mounting Type: Clip
• AC Max I.R./Breaking Capacity: I1: 200 kA
• kA Rating AC: 200
• kA Rating DC: 100
• Indication System: Yes
• Indication System Type: SmartSpot®
• Connection/Terminal Material: Tin-Plated Copper
• Connection/Terminal Type: Blade
• Product Diameter: 1.81 in
• Product Length: 9.63 in
• Product Weight: 1.46 lb
• Frequency: 50/60 Hz
• Body/Insulating Material: PolyTube
• Family: Amp-Trap 2000
• Type: A6D-R
• AIC Ratings: 200kA@600V
• ROHS Compliant: Yes
