Ferraz Shawmut 9F60DMH005 E-Rated Fuse 15500VAC 5A

Product Description

The FERRAZ SHAWMUT 9F60DMH005 is a medium voltage, E-rated fuse designed for the protection of transformers and distribution lines. This current-limiting fuse melts at current as low as 1.7 times the fuse current ratings, offering overload and short circuit protection. It is designed to withstand transformer magnetizing inrush current and features a DMH visual indicator and Amp-Trap(R) series.

• Medium Voltage E-Rated Fuse
• Provides overload and short circuit protection
• Features a DMH Visual Indicator

Product Highlights

Protects transformers and distribution lines with visual indication.

Product Information

Standard Information

• Brand: FERRAZ SHAWMUT
• Manufacturer Part Number: 9F60DMH005

Technical Specifications

• Voltage: 15500VAC
• Amperage: 5A
• Series: Amp-Trap 9F60/9F62 Series
• Fuse Type: E-Rated
• Application: Protection for 12 kV to 15.5 kV transformers or distribution systems.
• Type: Cylindrical Fuses
• Mounting: Clip
• Brand Name: Ferraz Shawmut
• Connection: Ferrule
• Manufacturer: FERRAZ SHAWMUT
• Voltage Rating: 15500 V
• Amperage Rating: 5 A
• Frequency (Hz): 50/60 Hz
• AC or DC: AC
• Speed/Characteristic: E-Rated
• AC Max I.R./Breaking Capacity: I1: 50 kA
• Indication System: Yes
• Indication System Type: Visual Indicator
• Connection/Terminal Material: Silver-Plated Copper
• Connection/Terminal Type: Ferrule
• Product Diameter: 2 in
• Product Length: 17.2 in
• Product group: Medium Voltage IEEE Fuses
• Body/Insulating Material: Epoxy
• Body Material: Epoxy
• Brand: Mersen
• Contact Material: Silver-Plated Copper
• Current Rating: 5 A
• Manufacturer Part Number: 9F60DMH005
• Primary Type: Single Use Fuses
• Standards: 9F62 UL listed to standard File E143362 A055F UL listed to standard File E143362
• Termination: Cartridge
