Falk Corp. MCG1500A-OACPLG | Orange Peel Motor Coupling Guard

Product Description

The Falk Corp. MCG1500A-OACPLG is an Orange Peel Motor Coupling Guard made from polyethylene material that meets safety compliance standards. This guard helps protect rotating equipment, ensuring a safer work environment while providing significant cost savings and easier maintenance. The design is tailored to fit between connected equipment and can be adjusted to your application dimensions. Optional risers can be included for added flexibility. It comes with stainless steel hardware for durability and is available in safety orange color.

• Patented trim and fit design
• Compatible with various motor sizes
• Easy installation with included stainless steel hardware

Product Highlights

The Orange Peel Motor Coupling Guard is built for safety and efficiency, providing a reliable solution for protecting machinery.

Product Information

Standard Information

• Brand: Falk Corp.
• Part #: 101904694

Technical Specifications

• Overall Height: 12.02 inches
• Motor Frame: 180-280
• Shaft Center Height without Riser [Max]: 7.5 inches
• Overall Length: 9.94 inches
• Type: Motor Coupling Guard
• Shaft Center Height without Riser [Min]: 4.5 inches
• Coupling O.D.: 6.38 inches
• Shaft Size [Max]: 2.130 inches
• Overall Width: 12 inches
• Weight: 3.1 LB
• EAN or UPC: 782934235498
