Falcon Stainless EXPT4 4.8 Gallon Potable Water Expansion Tank

Product Description

The FALCON STAINLESS EXPT4 4.8 Gallon Potable Water Expansion Tank is designed to protect water heaters from damage caused by thermal expansion. The 16 gauge cold rolled steel tank ensures longevity and durability. The 100% butyl diaphragm design delivers performance and ensures a leak-free operation. It has a factory pre-charge of 40 psi.

• Tank: 16 gauge cold rolled steel
• Finish: Appliance quality paint for indoor or outdoor installation
• Water chamber: 100% butyl rubber, lined with polypropylene

Product Highlights

Protects water heaters from thermal expansion damage with a durable steel tank and butyl rubber diaphragm.

Product Information

Standard Information

• Brand: FALCON STAINLESS
• Manufacturer Part Number: EXPT4

Technical Specifications

• Connection: 3/4 in MNPT
• Diameter: 8 in
• Maximum Working Pressure: 150 psig
• Maximum Working Temperature: 200 deg F
• Mfg Standards/Approvals: Certified to NSF Standard 61 Domestic Hot
• Pre-Charge: 40 psig
• Series: EXPT
• Tank Volume: 4.8 gal
• Warranty: 5 yr
• Recommended Use: Closed hot water heating systems including on water heaters and boilers
• Height: 14.5 inch
• Brand: Falcon Stainless Inc
• Category: Expansion Tank
