Fafnir G1108KPPB3 Ball Bearing Insert

Product Description

The Fafnir G1108KPPB3 is a ball bearing insert designed to fit standard housings. This product features a relubricatable Tri-Ply seal that protects against contamination and moisture, enhancing the bearing's durability. The unique shroud cap design aids in preventing abrasion.

• Insert has a one and a half inch internal diameter.
• Contains a double sealed contact for enhanced protection.
• Includes an eccentric locking collar for secure installation.

Product Highlights

The G1108KPPB3 is ideal for standard-duty applications requiring reliable performance in challenging environments.

Product Information

Standard Information

• Brand: Fafnir
• Part #: 100733883

Technical Specifications

• Lubrication: Relubricatable
• Overall Width: 1 and 11/16 inches
• Bore Type: Round Bore
• Seal Type: Contact Seals
• Outer Ring Width: 21 mm
• I.D.: 1.500 inches
• Inch/Metric: Inch Bore
• Length Through Bore: 1.6875 inches
• Static Load Rating [Max]: 4000 lbf
• O.D.: 80 mm
• Static Capacity: 4000 lbf
• Duty: Standard-Duty
• Locking Device: Eccentric Locking Collar
• Outer Ring Size: 208
• Material: Steel
• Bearing Type: Ball Bearing
• Enclosure: Double Sealed
• Rolling Element: Ball Bearing
• Bearing Design: Non-Expansion
• Dynamic Load Rating: 8150 lbf
• Weight: 1.8 LB
• EAN or UPC: 87796055506
