EQUIPMENT CONTROLS 30415 Rotary Switch

Product Description

The EQUIPMENT CONTROLS 30415 is a rotary switch designed for various applications. This switch has multiple poles and positions which allow flexibility in control systems. It features a detent mechanism that ensures accurate positioning. The design supports both panel and PCB mounting.

• Multi-pole and multi-position configurations
• Designed for panel and PCB mounting
• RoHS compliant

Product Highlights

This rotary switch is ideal for control applications where multiple configurations are necessary.

Product Information

Standard Information

• Manufacturer: C&K
• Part Number: A30415RNCB

Technical Specifications

• Number of Positions: 4
• Number of Decks: 1
• Number of Poles per Deck: 3
• Circuit per Deck: 3P4T
• Contact Timing: Non-Shorting (BBM)
• Current Rating (Amps): 2.5A (AC), 350mA (DC)
• Voltage Rating - AC: 125 V
• Voltage Rating - DC: 125 V
• Actuator Type: Flatted (6.35mm Dia)
• Actuator Length: 38.10mm
• Angle of Throw: 30 Degrees
• Contact Material: Silver (Ag)
• Contact Finish: Silver
• Mounting Type: Panel Mount, Through Hole
• Termination Style: PC Pin
• Depth Behind Panel: 14.48mm
• Panel Cutout Dimensions: Circular - 9.80mm Dia
