Emuge CU501000.5018 Spiral Flute Tap 1-8 Unc Cobalt

Product Description

The EMUGE CU501000.5018 is a spiral flute tap designed for cutting internal threads in blind hole applications. Built from cobalt high-speed steel with a bright/uncoated finish, this tap handles both non-ferrous metals and steel. It cuts a 1-8 UNC right-hand thread to a 2B class of fit, with a modified bottoming chamfer that allows threading closer to the bottom of a blind hole than a standard plug tap. The 35-degree helix angle evacuates chips upward, keeping the flutes clear during the cut. Four flutes provide good chip capacity and stable cutting action across a range of materials.

This tap is suited for machining and fabrication environments where 1-8 UNC threaded blind holes are required in steel or non-ferrous workpieces. The modified bottoming chamfer makes it a practical choice when full thread depth near the bottom of a hole is needed. Part of the EMUGE Enorm series, it is intended for use in CNC machining centers and manual tapping operations where consistent thread quality and tool longevity are priorities. Coolant-through is not supported on this tap.

Key Features

• Modified bottoming chamfer for threading close to the bottom of blind holes
• Cobalt construction for improved heat and wear resistance in steel and non-ferrous metals
• 35-degree right-hand helix angle promotes upward chip evacuation in blind hole work
• 2B class of fit for standard inch UNC thread tolerance requirements
• Four medium-style flutes for balanced chip capacity and cutting stability
• Part of the EMUGE Enorm series, designed for demanding production tapping applications

Compatibility

Designed for blind hole threading in non-ferrous metals and steel. Cuts 1-8 UNC right-hand threads to a 2B class of fit. Compatible with tap holders accepting a 0.800-inch shank diameter with a 0.600-inch square drive.

Installation Notes

Installation and use of this tap should be performed by a qualified machinist or tool-and-die professional. Ensure the workpiece is securely fixtured and the spindle or tapping head is properly aligned before engaging the tap. Power down the machine and relieve any stored energy before changing or inspecting tooling. Do not reverse the tap before it has completed its cut stroke in blind hole applications, as chip packing can cause tap breakage.
