Emerson ZS13KAE-TF5-818 Compressor, 200-230/3 1/2 inches x 3/4 inches

Product Description

The EMERSON ZS13KAE-TF5-818 is a compressor designed for HVAC applications. This scroll compressor is part of the ZSKA Series and is compatible with R404A refrigerant. It features a 3/4" suction line size and a 1/2" liquid line size, operating at 200/230V and 60 Hz.

• Features axial and radial compliance to protect against liquid damage.
• Operates at lower sound and vibration levels.
• Engineered for use with chlorine-free refrigerants.

Product Highlights

This compressor is designed for efficiency and reliability, with fewer moving parts and the ability to start under any system load.

Product Information

Standard Information

• Brand: EMERSON
• Manufacturer Part Number: ZS13KAE-TF5-818
• Country of Origin: United States

Technical Specifications

• RPM: 3500
• Type: Compressor
• Phase: 3
• Width: 9.69"
• Height: 15.72"
• Length: 9.69"
• Voltage: 200/230
• Frequency: 60 Hz
• Application: HVAC
• Refrigerant: R404A
• Series-Brand: ZSKA Series
• Compression Type: Scroll
• Liquid Line Size: 1/2"
• Suction Line Size: 3/4"
• Amperage Rating: 6.7 A
• BTU Rating: 13000 Btu/hr
• CFM Rating: 3.581 cfm
• Compressor Oil: POE-AK/DA, 3MA/SP32
• Discharge Line Size: 1/2 in Stub
• Flow Rate: 270 to 481 lb/hr
• Power Rating: 1-3/4 hp
• Refrigerant Type: R-22, R-134A, R-404A, R-407A, R-407C, R-448A, R-449A, R-507, R-410A
• Series: ZS
• Temperature Rating: 20 to 45 deg F Evaporator, 65 deg F Return Gas
• Voltage Rating: 200 to 230 VAC
• HP/Ton: 1.75
• Volts: 208/230
• Brand: COPELAND
• MPN: ZS13KAE-TF5-818
• Country of Origin: United States
