Elk Elk-100 High Performance Siren Driver Module

Product Description

The ELK ELK-100 siren driver is designed for residential and commercial security installations. It draws less current than most siren drivers and offers two simultaneous volume levels. The MilliMiser option further reduces current draw for controls with limited alarm or auxiliary output power. It features two inputs, Yelp & Steady, with the Steady sound overriding the Yelp.

• Two Volume Levels Simultaneously
• Draws Less Current Than Most Sirens
• MilliMiser Lowers Current Draw

Product Highlights

Ideal for security installations, this siren driver module offers efficient power usage and versatile sound options.

Product Information

Standard Information

• Brand: ELK
• Manufacturer Part Number: ELK-100

Technical Specifications

• Operating Voltage: 6 to 14 Volts DC
• Current Draw: 1.2 Amps, (700 mA on MilliMiser setting), with one 8 ohm speaker
• Sound Level: 120 db @ 1 meter, 14 vdc, with one 8 ohm speaker
• Max. Speaker Loading: 4 Ohms
• Size: 2.75" X 3.6" (70mm X 91mm)
• Manufacturer: ELK Products, Inc
• Part Number: 100
• Item model number: ELK-100
• Power Source: Battery Powered
• Voltage: 6 Volts (DC)
• Item Package Quantity: 1
• Mounting Type: Wall Mount
• Batteries Included?: No
• Batteries Required?: No
• Manufacturer Part #: ELK-100
• UPC: 762158001000
