Electro Hardware S1335-M07-F16-K Circuit Board Spacer

Product Description

The ELECTRO HARDWARE S1335-M07-F16-K is a round, female unthreaded circuit board spacer machined from 18-8 and 303 grade stainless steel. It accepts a 1/4 inch screw and measures 0.125 inches in overall length, with an inside diameter of 0.257 inches and an outside diameter of 0.500 inches. The uncoated finish meets QQ-S-763 fastener standards. This spacer is used to maintain precise standoff clearance between a circuit board and a mounting surface, preventing electrical shorts and ensuring proper airflow and vibration isolation in control assemblies. Electricians, HVAC technicians, and electronics service professionals install this hardware during control board replacements or panel fabrication.

This spacer is suited for residential and commercial control board assemblies where a low-profile, corrosion-resistant standoff is required. Its compact 1/8 inch overall length makes it appropriate for tight chassis installations where vertical clearance is limited. The stainless steel construction resists corrosion in environments that may be exposed to moisture or mild chemicals, making it a reliable choice for HVAC equipment enclosures, electrical control panels, and similar trade applications.

Key Features

• Female unthreaded design accepts 1/4 inch screws for secure board mounting
• 1/8 inch overall length provides low-profile standoff clearance
• 18-8 and 303 grade stainless steel construction for corrosion resistance
• Meets QQ-S-763 fastener standard
• Uncoated finish with tight length tolerance of -0.005 to 0.005 inches
• Inside diameter tolerance of 0.000 to 0.010 inches for consistent fit

Compatibility

Designed as a general-purpose OEM-style circuit board spacer for use in residential and commercial electrical and HVAC control panel assemblies requiring a 1/4 inch screw size and a 1/2 inch outside diameter round standoff.

Installation Notes

Installation is performed by licensed electricians or HVAC technicians. Always de-energize and lock out the control panel before servicing circuit boards or replacing mounting hardware. Verify the spacer seating is flush and the board is fully supported before reinstalling fasteners. Follow applicable NEC guidelines when working inside electrical enclosures.
