Edwards Signaling 48XBRMB120A Led Signal Light 120VAC

Product Description

The EDWARDS SIGNALING 48XBRMB120A is a dual-mode LED signal light that operates in both flashing and steady output modes with a blue lens. Designed for panel or half-inch pipe mounting, this unit runs on 120VAC and draws only 0.11 amps. The LED light source delivers a flash rate of 65 flashes per minute in flashing mode. Built to NEMA 4X standards, the housing is impact-resistant, shatter-resistant, vibration-resistant, and weatherproof, making it suitable for demanding indoor and outdoor environments. Licensed electricians and industrial maintenance technicians are the primary installers for this type of signaling device.

This signal light is suited for commercial and industrial applications where visual alerting is required in wet, dusty, or corrosive environments. The NEMA 4X rating makes it appropriate for outdoor enclosures, wash-down areas, food processing zones, and similar harsh-duty settings. The panel mount option fits flush into a control panel cutout while the half-inch pipe mount option accommodates standard conduit or pendant mounting. Its rated operating temperature range of -31 degrees F to 150.80 degrees F extends usability across cold storage, rooftop, and high-ambient-temperature installations.

Key Features

• Dual operating modes: flashing at 65 flashes per minute and continuous steady output
• Blue LED lens for color-coded visual signaling
• NEMA 4X rated: weatherproof, impact-resistant, shatter-resistant, and vibration-resistant
• Operates on 120VAC at 0.11 amps for low power draw
• Panel mount or half-inch pipe mount configurations
• Wide operating temperature range: -31 degrees F to 150.80 degrees F
• cULus and UL Listed for North American code compliance

Compatibility

Designed as an OEM-style visual signaling unit for industrial control panels, machinery, and process equipment requiring panel or half-inch pipe mount LED signal lights rated for NEMA 4X environments.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. Disconnect and lock out all power to the panel or mounting surface before beginning installation. Verify the mounting cutout or pipe stub dimensions match the unit specifications before securing the fixture. Do not exceed the rated voltage or expose the unit to environments beyond its listed NEMA rating without additional protective measures.
