Eclipse M19170/MSC Alnico Pot Magnet 0.17 Lb 6-32 Thread

Product Description

The ECLIPSE M19170/MSC is an Alnico pot magnet designed for holding and fastening applications requiring a threaded mounting interface. Built from Alnico 5 material, this magnet delivers an average pull force of 0.17 pounds and a maximum pull force of 0.3 pounds. The 6-32 threaded stud allows direct installation into tapped holes or with a mating nut for secure fixture. With a maximum operating temperature of 428 degrees F, this magnet is suited for environments where elevated heat is a factor. It measures 1/4 inch in diameter and 3/4 inch in height, making it compact for tight mounting locations.

This pot magnet is used in light-duty holding, latching, and positioning applications across industrial, commercial, and workshop settings. Typical uses include sensor mounting, fixture holding, and component positioning on ferrous surfaces. The threaded stud design makes it straightforward to integrate into assemblies where a mechanical fastener and magnetic retention are both needed in a single compact unit. Electricians, maintenance technicians, and fabricators commonly work with this style of magnet in panel, enclosure, and fixture builds.

Key Features

• Alnico 5 magnet material for reliable pull force and high-temperature stability
• Average pull force of 0.17 pounds with maximum pull force of 0.3 pounds
• 6-32 threaded stud for direct mechanical integration into assemblies
• Maximum operating temperature of 428 degrees F suits elevated-heat environments
• Compact size at 1/4 inch diameter and 3/4 inch height for space-constrained installs

Compatibility

Designed as a standard Alnico pot magnet with a 6-32 threaded stud for use on ferrous surfaces in general industrial and commercial holding applications.

Installation Notes

Installation requires access to a tapped 6-32 hole or use of a matching nut on the threaded stud. Ensure the mating ferrous surface is clean and flat for full pull-force engagement. Avoid shock loading or side-loading the magnet beyond its rated pull force, as Alnico material can be brittle. No special tools are required beyond standard hand tools appropriate for 6-32 fasteners.
