Eaton XTPR058DC1 Iec D Frame Overload Relay 55A

Product Description

The EATON XTPR058DC1 is an IEC-style D Frame overload relay designed to protect motors and electrical loads from sustained overcurrent conditions. This relay monitors current draw and trips the control circuit when current exceeds the set threshold, preventing motor burnout and equipment damage. The D Frame form factor positions it as a component-level device intended for integration into motor starter assemblies and control panel builds. Licensed electricians and industrial control technicians are the primary installers of this device.

The XTPR058DC1 is suited for use in industrial and commercial motor control applications where IEC-style components are specified. It is typically paired with a matching IEC contactor in a full-voltage motor starter configuration. The D Frame sizing accommodates mid-range motor loads, making it a common selection for pump, fan, conveyor, and compressor motor protection circuits in both new panel builds and replacement scenarios.

Key Features

• IEC D Frame overload relay for motor overcurrent protection
• Designed for integration with IEC motor starter contactors
• Suitable for mid-range industrial and commercial motor control applications
• Compact frame design supports panel-space-efficient installations

Compatibility

Designed as an OEM-style IEC D Frame overload relay for use in compatible IEC motor starter and contactor assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lock out the panel or control circuit before installing or replacing the overload relay. Verify that the overload relay current range is correctly set to match the full-load amperage of the motor being protected before returning the circuit to service.

Technical Specifications

• Frame Size: IEC D Frame
• Weight: 2.5 pounds
• UPC: 01508154843

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTPR058DC1
