Eaton XTOE1P6BCS Electronic Overload Relay

Product Description

The EATON XTOE1P6BCS is an electronic overload relay designed to protect single-phase and three-phase motor circuits from overload and phase-loss conditions. Electronic overload relays monitor motor current continuously and trip the circuit when current exceeds the set threshold, preventing motor burnout and reducing downtime. This unit measures 7.5 inches long by 3 inches wide by 6.5 inches tall and weighs 0.87 pounds, making it a compact addition to motor control panels, starters, and control enclosures. Installation is typically performed by licensed electricians working on motor control applications in commercial and industrial settings.

The XTOE1P6BCS is suited for motor protection applications in commercial and industrial control panels. It is designed for use with motor starters and contactors where reliable overload protection is required. Typical installation scenarios include HVAC air handling units, pump motors, compressor circuits, and general-purpose motor loads that require continuous overcurrent monitoring and automatic trip functionality.

Key Features

• Electronic overload sensing for accurate, reliable motor protection
• Compact form factor fits standard motor starter and control enclosure mounting positions
• Continuous current monitoring with automatic trip on overload condition
• Lightweight construction at 0.87 pounds for easy panel integration
• UPC verified unit: 78668541639

Compatibility

Designed as an OEM-style replacement electronic overload relay for use with compatible EATON motor starters and contactors in commercial and industrial motor control applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local electrical codes. De-energize and lock out the circuit at the disconnect before handling or replacing any overload relay. Verify that the relay current range is properly set to match the full-load amp rating of the motor before returning the circuit to service. Do not bypass the overload relay for test purposes.

Technical Specifications

• Length: 7.5 inches
• Width: 3 inches
• Height: 6.5 inches
• Weight: 0.87 pounds
• UPC: 78668541639

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTOE1P6BCS
