Eaton XTCE009B01TD Full Voltage Contactor

Product Description

The EATON XTCE009B01TD is a full voltage contactor designed for switching and controlling electrical loads in commercial and industrial power distribution systems. Full voltage contactors handle the direct energizing of motor loads and resistive loads at line voltage without reduced-voltage starting circuits. This unit is installed by licensed electricians and industrial maintenance technicians in motor control centers, control panels, and machinery enclosures where reliable, repeated switching of electrical loads is required.

The XTCE009B01TD is suited for motor control and load switching applications in commercial and light industrial settings. Typical installations include HVAC motor starters, pump control panels, compressor circuits, and general-purpose machinery. This contactor is designed for panel-mount integration in environments requiring durable, code-compliant switching components.

Key Features

• Full voltage switching operation for direct motor and resistive load control
• Compact contactor form factor suited for panel and motor control center mounting
• Designed for repeated switching cycles in demanding commercial and industrial service
• Compatible with standard control voltage coil connections for integration into existing control circuits

Compatibility

Designed as an OEM-style replacement or new-installation contactor for full voltage motor control and load switching applications in commercial and industrial electrical systems.

Installation Notes

Installation must be performed by a qualified, licensed electrician in accordance with applicable NEC requirements and local codes. De-energize and lock out the panel or motor control center before beginning any wiring or mounting work. Verify coil control voltage matches the supply before energizing the contactor. Follow the manufacturer wiring diagram for proper line, load, and coil terminal connections.

Technical Specifications

• Type: Full Voltage Contactor
• UPC: 01508276740

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTCE009B01TD
