Eaton sqd-qo235 Miniature Circuit Breaker 35A 2P 120/240V

Product Description

The EATON sqd-qo235 is a 2-pole miniature circuit breaker rated for 35 amps at 120/240 volts with a 10 kA interrupt capacity. It provides overcurrent and short-circuit protection in residential and light commercial electrical panels. The breaker is designed for reliable branch circuit protection and fits into compatible load centers. Licensed electricians install this device as part of new construction wiring or panel upgrades. Its compact form factor and dual-pole design make it suitable for 240-volt branch circuits such as dryer circuits, HVAC equipment feeds, and similar loads.

This circuit breaker is used in residential and light commercial electrical distribution panels where 2-pole, 35-amp branch circuit protection is required. Typical applications include protecting 240-volt loads such as electric heating equipment, air conditioning units, and large appliances. It is installed in load centers that accept QO-series breakers and is commonly specified during panel upgrades, new construction, or breaker replacement service calls.

Key Features

• 35-amp continuous current rating for 240-volt branch circuit protection
• 2-pole design handles double-pole 120/240-volt circuits in a single breaker slot pair
• 10 kA interrupt capacity for short-circuit protection
• Compact miniature circuit breaker form factor for load center installation
• Suitable for residential and light commercial panel applications

Compatibility

Designed as an OEM-style replacement miniature circuit breaker for load centers accepting QO-series 2-pole breakers.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the panel and verify the absence of voltage before handling any breaker or wiring. Do not install a breaker with a higher amperage rating than the circuit conductors are sized to carry. Confirm the load center accepts QO-series breakers before installation.

Technical Specifications

• Amperage: 35 amps
• Poles: 2
• Voltage Rating: 120/240 volts
• Interrupt Capacity: 10 kA

Standard Information

• Brand: EATON
• Manufacturer Part Number: sqd-qo235
