Eaton S-8202-2 Buss Fuseblock 300 VAC/VDC 16/20 A 2 Poles

Product Description

The Eaton S-8202-2 Buss Fuseblock is designed for reliable electrical connections in various applications. It supports a voltage rating of 300 VAC/VDC and can handle amperage ratings of 16/20 A. This fuse block features a breakaway design with a quick-connect connection for easy installation.

• Voltage rating: 300 VAC/VDC
• Amperage rating: 16/20 A
• Dimensions: 2 inches long, 0.5 inches wide, 0.56 inches high

Product Highlights

This Buss Fuseblock is ideal for use in electrical systems requiring quick and efficient connections. Its sturdy thermoplastic construction ensures durability and temperature ratings up to 130 degrees Celsius.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171211760

Technical Specifications

• Type: Breakaway
• Connection Type: Quick-Connect
• Material: Thermoplastic
• Mounting Type: Bolted-In
• Number of Poles: 2
• Fuse Diameter: 1/4 inch
• Fuse Length: 1-1/4 inch
• Temperature Rating: 130 degrees Celsius
• Series: 8200
• Standards/Approvals: UL File No. E14853 Guide No. IZLT2|CE Certified|CSA 6225-01 File No. 47235
