Eaton M22-WRLK-W Knob Type Rotary Operator 22.5 Mm

Product Description

The EATON M22-WRLK-W is a knob-type rotary operator designed for use with 22.5 mm modular control devices in industrial and commercial control panel applications. This component serves as the manual actuator that interfaces with an underlying contact block or selector switch body to allow an operator to rotate and lock switch positions. It is built to the M22 modular system standard and is installed by licensed electricians and control panel builders working on machine control, motor starter, and process automation equipment.

This rotary operator is suited for use in industrial control panels, machine tool enclosures, and commercial electrical equipment where a secure, lockable knob-type actuator is required. The 22.5 mm mounting footprint makes it compatible with standard 22.5 mm cutout panel installations, a common format in both domestic and international control system builds. It is appropriate for both new panel construction and replacement service in existing M22-series installations.

Key Features

• Knob-type rotary actuator with locking capability for secure operator control
• 22.5 mm modular mounting format for standard panel cutout compatibility
• Designed for use within the M22 modular operator and contact block system
• Compact profile suitable for high-density control panel layouts
• White knob finish for clear visual identification on panel faces

Compatibility

Designed as an OEM-style replacement or new-installation actuator for 22.5 mm modular control device assemblies within the M22 product series.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and applicable local codes. De-energize the control panel and verify lockout/tagout procedures are in place before servicing or replacing any panel-mounted operator. The actuator mounts through a standard 22.5 mm panel cutout and secures to the underlying contact block or switch body per the modular assembly instructions. Do not force the locking mechanism or overtighten the mounting hardware.

Technical Specifications

• Mounting Size: 22.5 mm
• Operator Type: Knob Type Rotary with Lock
• Package Dimensions (L x W x H): 7 inches x 5 inches x 1.5 inches
• Weight: 0.05 pounds
• UPC: 78668528184

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22-WRLK-W
