Eaton M22-PVLT45P Illuminated Push Button Operator 22mm

Product Description

The EATON M22-PVLT45P is a 22mm illuminated push button operator finished in red, designed for use in industrial control panels and electrical enclosures. This operator serves as the front-mounted actuator in modular M22 series control station assemblies, working in conjunction with compatible contact blocks and lamp modules to complete a functional pushbutton station. Licensed electricians and industrial control technicians install this component during panel builds or field replacements. At 0.98 inches in depth, the operator mounts through a standard 22mm panel cutout and connects to the modular rear contact elements without additional tools beyond basic hand tools.

This push button operator is suited for industrial and commercial electrical control applications including motor control centers, machine control panels, operator interface stations, and process control enclosures. The red illuminated lens is a standard industry color for stop, emergency, or fault-indication functions, making it appropriate for circuits where visual status feedback is required at the operator level. It is intended for use within the EATON M22 series modular system.

Key Features

• 22mm mounting diameter fits standard 22mm panel cutouts
• Red illuminated operator face for stop or fault-indication applications
• Modular M22 series design - mates with compatible M22 contact blocks and lamp modules
• Compact depth of 0.98 inches minimizes panel space requirements
• Footprint of 2.01 inches x 2.01 inches for front-panel clearance planning

Compatibility

Designed as an OEM-style modular operator for use within the EATON M22 series 22mm control device platform, requiring compatible M22 series contact blocks and lamp modules to form a complete pushbutton station.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and the enclosure manufacturer's guidelines. De-energize and lock out the control panel before installing or replacing any operator or contact block assembly. Mount through a 22mm panel cutout and secure with the manufacturer's retaining hardware before attaching rear contact modules. Verify lamp module and contact block compatibility within the M22 series before finalizing the assembly.
