Eaton M22-DDL-GR Extended Pilot Light Lens Green

Product Description

The EATON M22-DDL-GR is an extended-type lens cap designed for M22 series pilot light assemblies used in industrial control panels and machinery. The green lens provides a clear visual indicator for status monitoring in control station and enclosure applications. Weighing under 1 pound, this lens cap is a direct component in pushbutton and pilot light assemblies where a protruding, extended-format lens is required for operator visibility. Electricians and panel builders handling industrial control wiring will find this part fits the M22 component system used across a wide range of machine control and process automation panels.

This extended-type lens is suited for use in industrial and commercial control panel builds, operator interface stations, and machine tool enclosures. It is appropriate for applications where green status indication is the standard — typically to signal a running, active, or safe condition. Installation is common in both OEM panel fabrication and retrofit or replacement scenarios on existing M22-footprint assemblies.

Key Features

• Extended-type lens format for increased operator visibility in control station applications
• Green color — standard for run, active, or safe-state indication in industrial controls
• Designed for M22 series pilot light and pushbutton assemblies
• Lightweight construction at under 1 pound for easy handling and installation

Compatibility

Designed as an OEM-style component for EATON M22 series pilot light assemblies used in industrial control panel and operator station applications.

Installation Notes

Installation is typically performed by a licensed electrician or qualified panel builder. De-energize the control panel and follow lockout/tagout procedures before servicing any pilot light assembly. The lens cap is a mechanical fit component and should be seated securely to ensure proper light transmission and enclosure integrity. Verify the lens color and format against the existing assembly specification before installing.

Technical Specifications

• Lens Type: Extended
• Color: Green
• Weight: 0.995 pounds
• UPC: 78668527225

Standard Information

• Brand: EATON
• Manufacturer Part Number: M22-DDL-GR
