Eaton LP-CC-8/10 Buss Low Peak TD Class CC

Product Description

The Eaton LP-CC-8/10 is a Bussmann Low Peak time delay fuse designed for current limiting applications. This fuse operates at an amperage rating of 0.8 A and is rated for 600 VAC and 300 VDC. It provides reliable protection in small horsepower motor circuits, ideal for industrial facilities and specialized circuit applications.

• Time delay characteristic prevents nuisance openings from surge currents.
• Compact design with dimensions of thirteen thirty-seconds inches in diameter and one and one-half inches in length.
• Rejection type ensures compatibility with specific fuse holders and systems.

Product Highlights

Offers effective protection for branch circuits and meets various industry standards.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 05171218042

Technical Specifications

• Amperage Rating: 0.8 A
• Voltage Rating: 600 VAC / 300 VDC
• Body Size: 13/32 in Dia x 1-1/2 in L
• Class: CC
• Interrupt Rating: 200 kAIC
• Response Time: 12 s at 200%
• Terminal Type: Ferrule End
• Material: Melamine Tube
• Mounting Type: Holder
• Standards: CE Certified, CSA File No.53787, RoHS Compliant
