Eaton JD3200 Series C J Frame Molded Case Circuit Breaker 200 A 600 Vac 250 Vdc

Product Description

The Eaton JD3200 is a Series C Molded Case Circuit Breaker designed for reliable electrical protection. This circuit breaker features a J-frame configuration, with a current rating of two hundred amperes, and is suitable for both 600 VAC and 250 VDC applications.

• Three-pole configuration
• Fixed thermal and magnetic trip technology
• Suitable for use in panelboards and switchboards

Product Highlights

The Eaton JD3200 circuit breaker is engineered for high performance and durability. It provides essential protection for electrical assemblies and motor control centers, supporting a frequency of fifty to sixty Hertz.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: JD3200

Technical Specifications

• Voltage Rating: 600 VAC / 250 VDC
• Current Rating: 200 A
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: 3
• Interrupt Rating: 65 kAIC at 240 VAC | 35 kAIC at 480 VAC
• Frame Type: J
• Enclosure Material: Stainless Steel
• Dimensions: 4.06 inches (Length) x 4.13 inches (Width) x 4.13 inches (Height)
