Eaton GMT-2A BUS IND FUSE (10)

Product Description

Eaton's GMT-2A is a fast-acting telecommunication fuse designed for applications requiring reliable circuit protection. This fuse has a current rating of two amperes and operates at 125 volts alternating current or 60 volts direct current. It features a maximum interrupting rating of 300 amperes at 125 volts AC and 450 amperes at 60 volts DC.

• Voltage Rating: 125 VAC / 60 VDC
• Interrupt Ratings: 300 A at 125 VAC, 450 A at 60 VDC
• Mounting Type: Snap-In

Product Highlights

The fuse includes local and remote indication capability. It is also color-coded for easy identification of the amp rating. The flat body is designed for quick-connect terminal installations.

Product Information

Standard Information

• Manufacturer: Eaton
• Manufacturer Part Number: GMT-2A

Technical Specifications

• Amperage Rating: 2 A
• Application: IT and data communication, telecommunications circuit protection
• Body Size: 0.81 inches L x 0.688 inches H
• Body Type: Flat
• Color: Orange
• Element: Single
• Material: Thermoplastic Tin Plated Beryllium Copper
• Mounting Type: Snap-In
• Series: GMT
• Standards/Approvals: CE Certified, RoHS Compliant, UL Guide JFHR2/E56412
• Terminal Type: Quick-Connect
• Type: Fast Acting
• Voltage Rating: 125 VAC / 60 VDC
