Eaton GHB3050 C Series Type GHB Molded Case Circuit Breaker 480Y/277 VAC/125/250 VDC 50 A 65/14 kA Interrupt 3 Poles

Product Description

The Eaton GHB3050 is a molded case circuit breaker designed for reliability and performance in various electrical applications. This product supports a voltage rating of 480Y/277 VAC and 125/250 VDC, with a current rating of fifty amps. It incorporates a three-pole configuration and features a fixed thermal and magnetic trip type. The breaker provides an interrupt rating of sixty-five and fourteen kiloamperes.

• Max Voltage: 480Y/277 VAC, 125/250 VDC
• Current Rating: 50 A
• Number of Poles: 3

Product Highlights

This Eaton circuit breaker is suitable for use in panelboards, switchboards, and motor control centers. It is compatible with systems requiring dependable circuit protection, meeting North American standards.

Product Information

Standard Information

• Manufacturer: Eaton
• Series: C Series

Technical Specifications

• Type: GHB
• Frame: G
• Phase: 3
• Trip Type: Fixed Thermal/Fixed Magnetic/Non-Interchangeable
• Wire Size: 10 to 1/0 AWG
• Dimensions: 6.6 in L x 3.8 in W x 4 in H
• Enclosure Type: NEMA 4
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 14 kAIC at 480Y/277 VAC
