Eaton FH14 Overload Relay Heater

Product Description

The Eaton FH14 is an overload relay heater identified by a catalog number stamped on one terminal. It protects motors based on their full load current and service factor. Heaters should be selected based on the actual full load current and service factor as indicated on the motor nameplate. It is designed for NEMA 0/1/2 enclosures.

• Select heater coils based on full load current (FLA) shown on motor nameplate
• Type A and B overload relay
• Heater coils are rated to protect 40 deg C rise and a service factor of 1.15

Product Highlights

The Eaton FH14 overload relay heater is used with starter sizes 0, 1, and 2, and features both thermal and fast trip functionality.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FH14

Technical Specifications

• Enclosure Type: NEMA 0/1/2
• Full Load Current: 0.76 to 0.83/0.88 to 0.96 A Ambient, 0.71 to 0.77/0.86 to 0.94 A Non-Comp
• Trip Type: Fast/Thermal
• Type: Type B100
• Used with Starter Sizes: 0,1, and 2
• Thermal and Fast Trip: True
• Standard: CSA,UL
• Brand: Eaton
• Product Name: Eaton A200/B100 heater
• Catalog Number: FH14
• Product Length/Depth: 2.1 in
• Product Height: 0.8 in
• Product Width: 1.3 in
• Certifications: CSA Certified, UL Listed
• Global Catalog: FH14
• Product Type: Heater
• Special features: Used with Starter Sizes 0,1, and 2
• Used with: Used with Starter Sizes 0,1, and 2
• Design: NEMA
• Full load current range: Ambient 0.76-0.83, 0.88-0.96 A, Non-Comp 0.71-0.77, 0.86-0.94 A
• Overload relay: Type A and B
• Full Load Current Rating: 0.76 to 0.83/0.88 to 0.96 A
• Series: A200/B100
• Amps: 0.960
• Amps Range: 0.710 - 0.960
