Product Description
The EATON FH07 is an overload relay heater designed for thermal overload relays, magnetic motor starters, and motor controls. Heaters should be selected based on the motor's full load current. It protects against overheating by prompting contactors to break electrical connections when a set temperature is reached.
- Select heater coils based on full load current (FLA) shown on motor nameplate
- Heater coils are rated to protect 40 deg C rise and a service factor of 1.15
- Type A and B overload relay
Product Highlights
The EATON FH07 is a heater element used for thermal overload protection in motor control applications.
Product Information
Standard Information
-
Brand: EATON
-
Manufacturer Part Number: FH07
-
Country of Origin: Dominican Republic
Technical Specifications
-
Full Load Current: 0.39 to 0.42/0.44 to 0.48 A Ambient, 0.36 to 0.39/0.43 to 0.47 A Non-Comp
-
Trip Type: Fast/Thermal
-
Type: Type B100
-
Brand: Eaton/Cutler-Hammer
-
Series: A200/B100
-
Amperage: 0.43-0.47
-
Protection: Thermal
-
For Use With: Thermal Overload Relays, Magnetic Motor Starters and Motor Controls
-
Mpn: FH07
-
Upc: 786678629087
-
Gtin: 786678629087
-
Compatible with Series: A200; B100
-
Trip Class: 20
-
Overload Protection Type: Thermal
-
Compatible with Grainger Part Number: 11Z488; 11Z489; 11Z49; 11Z491; 11Z492; 11Z493; 11Z494; 11Z495; 11Z496; 11Z497
-
Compatible with Manufacturer Model Number: B100J0B; B100J0C; B100J1B; B100J1C; B100M0B; B100M0C; B100M1B; B100M1C; B100S0B; B100S0C; B100S1B; B100S1C; B100U0B; B100U0C; B100U1B; B100U1C; B100W0B; B100W0C; B100W1B; B100W1C
-
Full Load Current Rating: 0.39 to 0.42/0.44 to 0.48 A
-
Standard & Approvals: UL Listed, CSA Certified
-
Manufacturer: Eaton
-
Frame Type: Heater
-
Primary brand: Eaton
-
Secondary brand: Cutler-Hammer
-
Main function: Spare part
-
Sub-range name: FH
-
Functions: Replacement heater element
-
Technical compatibility with: A200 series Size 0 overl. rlys
