Eaton FD3020 breaker ckt case mld 600VAC/250VDC 20A

Product Description

The Eaton FD3020 is a molded case circuit breaker designed for applications up to six hundred volts alternating current or two hundred fifty volts direct current. This three-pole breaker supports a current rating of twenty amperes and features long time and instantaneous trip settings. It is a reliable solution for panelboards, switchboards, motor control centers, and busway applications.

• Voltage Rating: 600 VAC/250 VDC
• Amperage Rating: 20 A
• Interrupt Rating: 25 kA

Product Highlights

This circuit breaker meets North American standards, providing dependable branch circuit protection. Its compact design allows for easy panel mounting and it supports wire sizes from fourteen to one-aught AWG.

Product Information

Standard Information

• Manufacturer: Eaton
• Type: Molded Case Circuit Breaker

Technical Specifications

• Frame: F
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Temperature Rating: 40 deg C
• Enclosure Type: NEMA AB1/AB3
• Connection Type: Load Lug
