Eaton FAZ-K40/2 supplementary protector 40 A 2 pole

Product Description

The EATON FAZ-K40/2 is a DIN rail mountable supplementary protector designed for control panel applications. This 2-pole device offers 40 A overcurrent protection with a K-Curve trip characteristic, suitable for highly inductive loads. It features a 480Y/277 VAC voltage rating and an IP20 enclosure, ensuring protection for personnel and installations. The unit supports 18 to 4 AWG wire with line/load side standard terminal connections.

• Current limiting design provides fast short-circuit interruption.
• Features thermal magnetic overcurrent protection.
• K-Curve trip characteristic for specific short circuit protection.

Product Highlights

Provides reliable thermal magnetic overcurrent protection for highly inductive loads in control panel applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-K40/2

Technical Specifications

• Series: FAZ
• Material: Nylon
• Trip Type: K-Curve
• Wire Size: 18 to 4 AWG
• Mounting Type: DIN Rail
• Enclosure Rating: IP20
• Input Voltage: 480Y/277 VAC
• Amperage Rating: 40 A
• Connection Type: Line/Load Side Standard Terminal
• Number of Poles: 2
• Interrupt Rating: 7.5/15 kA
• Operating Temperature: -40 to 167 deg F
• Certifications: UL 1077, IEC 60947-2, CSA Std. C22.2 No.235, UR, CE
• Product Type: Supplementary Protector
• Product Series: xEffect
• Network Frequency: 50/60 Hz
• Rated Voltage (DC): 96Vdc (UL; 2 poles in series)
• Rated Impulse Voltage (Uimp): 4 kV
• Rated Insulation Voltage (Ui): 440 V
• Ultimate Short Circuit Breaking Capacity (Icu): 10kA (415Vac)
• Service Short Circuit Breaking Capacity (Ics): 7.5kA (415Vac)
• Service Short Circuit Breaking Capacity as Percentage of Icu: 75 %
• Size in Modules: 2 Module(s)
• Visual Position Indicator: Contact position indicator red-green
• Mechanical Durability: 10 000 operations
• Trip Characteristic: 8-12X /n
• Short Circuit Current Rating (UL1077): 5kA
