Eaton FAZ-C5/2 supplementary protector 5 A

Product Description

The Eaton FAZ-C5/2 supplementary protector is a UL 1077 industrial miniature circuit breaker suitable for applications where medium levels of inrush current are expected. This two-pole unit with a C curve provides protection for small transformers and pilot devices. It has a 5 A amperage rating and a 15 kAIC interrupt rating.

• UL 1077 Industrial miniature circuit breaker - supplementary protector
• Suitable for applications where medium levels of inrush current are expected
• Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.

Product Highlights

The Eaton FAZ-C5/2 supplementary protector provides reliable circuit protection in commercial environments.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C5/2

Technical Specifications

• Product Name: Eaton FAZ supplementary protector
• Catalog Number: FAZ-C5/2
• EAN: 4015082787530
• Product Length/Depth: 1.38 in
• Product Height: 1.38 in
• Product Width: 1.5 in
• Certifications: IEC 60947-2 CSA Std. C22.2 No.235 UL 1077
• Product Type: Supplementary protector
• Number of poles: Two-pole
• Terminals: Standard
• Type: UL 1077 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 5 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 15 kAIC
• Application: Suitable for applications where medium levels of inrush current are expected
• Series: FAZ
• Voltage: 480Y/277VAC, 96VDC
• Poles: 2
• Phase: 1
• AIC Rating: 10kA @ 480Y/277VAC, 10kA @ 96VDC
• Mounting Style: DIN Rail
• Terminal Type: Box Lugs
• For Use With: DIN Rail Systems, Industrial Control Panels
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Curve: C
• Trip Adjustability: Fixed
• Wire Gauge: 18-4 AWG
• Max Wire: 4 AWG
• Min Wire: 18 AWG
• Available Options: Auxiliary Switch, Shunt Trip, Undervoltage Release, Lockout Attachment, Busbar System
• Standards: CSA C22.2 No. 235, IEC 60947-2, UL 1077
• Approval: ABS, CCC, CE, CSA, DNV, GL, IEC, Lloyd's, RoHS, UL, VDE
• Temp Rating: -40C to 75C
• Construction Features: Current Limiting, Visual Trip Indicator, Trip-Free Mechanism, Reverse Feed
• Voltage Rating - AC: 415 V
• Voltage Rating - DC: 96 V
• Actuator Type: Lever
• Part Status: Active
• Illumination: None
• Breaker Type: Thermal Magnetic
