Eaton FAZ-C3/3-NA FAZ branch protector 3 A

Product Description

The EATON FAZ-C3/3-NA is a FAZ branch protector, which is a UL 489 industrial miniature circuit breaker. It is a supplementary protector suitable for applications where medium levels of inrush current are expected. It features screw terminals and a C curve for circuit protection.

• UL 489 Industrial miniature circuit breaker - supplementary protector
• Suitable for applications where medium levels of inrush current are expected
• Designed for use in branch service applications

Product Highlights

The EATON FAZ-C3/3-NA branch protector provides reliable protection for personnel, installations, and plant equipment.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C3/3-NA

Technical Specifications

• Product Name: Eaton FAZ branch protector
• Catalog Number: FAZ-C3/3-NA
• EAN: 4015081021178
• Product Length/Depth: 2.1 in
• Product Height: 4.13 in
• Product Width: 2.97 in
• Certifications: UL 489 CSA Std. C22.2 No. 235
• Catalog Notes: Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
• Product Type: Branch protector
• Number of Poles: Three-pole
• Terminals: Screw
• Type: UL 489 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 3 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 10 kAIC 14 kAIC
• Trip Type: 5-10X /n
• Voltage rating: 277/480V
• Application: Suitable for applications where medium levels of inrush current are expected
• UNSPSC Code: 39120000
• Actuator Type: Toggle
• Brand: Eaton - Cutler Hammer
• Characteristic: C Curve
• Current Rating: 3 A
• Mounting Type: DIN Rail Mount
• Series: FAZ Series
• Standards: UL 489
• UPC Code: 4015081021178
• Voltage Rating - AC: 415 V
• Voltage Rating - DC: 96 V
• Part Status: Active
• Illumination: None
• Breaker Type: Thermal Magnetic
• Approval Agency: ABS, CSA C22.2 No 5, UL489, VDE
• Moisture Sensitivity Level (MSL): Not Applicable
• ECCN: EAR99
• HTSUS: 8536.20.0020
• Poles: 3
• Volts DC: 48
• Volts AC: 277, 480Y
• Mounting: DIN Rail
• Amps: 3
• Family / Style: FAZ-NA
• Interrupt Rating AC: 10 kA
• Connection Type: Screw/Standard Terminal
• Temperature Rating: 40 deg C
• Wire Size: 18 to 6 AWG
• Standard & Approvals: VDE Certified, CSA C22.2 File No. 5, CE Certified, NEC Certified, CEC Certified, IEC 60947-2, UL 489, UL File No. E235139
