Eaton FAZ-C16/3 Supplementary Protector 16A

Product Description

The Eaton FAZ-C16/3 supplementary protector is a UL 1077 industrial miniature circuit breaker designed for supplementary protection. Suitable for applications where medium levels of inrush current are expected. It features a 16 A amperage rating, 15 kAIC interrupt rating, and a C curve for circuit protection.

• UL 1077 industrial miniature circuit breaker
• Suitable for medium levels of inrush current
• Features a C curve for circuit protection

Product Highlights

Eaton's FAZ-C16/3 supplementary protector provides reliable circuit protection in industrial applications with medium inrush currents.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C16/3

Technical Specifications

• Product Name: Eaton FAZ supplementary protector
• Catalog Number: FAZ-C16/3
• EAN: 4015082788735
• Product Length/Depth: 2.07 in
• Product Height: 2.07 in
• Product Width: 2 in
• Certifications: CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
• Product Type: Supplementary protector
• Number of poles: Three-pole
• Terminals: Standard
• Type: UL 1077 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 16 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 15 kAIC
• Trip Type: 5-10X /n
• Application: Suitable for applications where medium levels of inrush current are expected
• Mounting Type: DIN Rail Mount
• Voltage Rating: 240 V
• Characteristic: C Curve
