Eaton FAZ-C1/2 Supplementary Protector 1 A

Product Description

The Eaton FAZ-C1/2 supplementary protector is a UL 1077 industrial miniature circuit breaker. It is designed for applications where medium levels of inrush current are expected, providing protection for small transformers and pilot devices. It has a C curve and standard terminals.

• Suitable for applications where medium levels of inrush current are expected
• Two-pole
• Standard terminals

Product Highlights

The Eaton FAZ supplementary protector provides reliable circuit protection with a focus on safeguarding personnel, installations, and plant equipment.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C1/2

Technical Specifications

• Product Name: Eaton FAZ supplementary protector
• Catalog Number: FAZ-C1/2
• EAN: 4015082787455
• Product Length/Depth: 3.5 in
• Product Height: 1.5 in
• Product Width: 3 in
• Certifications: UL 1077 IEC 60947-2 CSA Std. C22.2 No.235
• Catalog Notes: Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
• Product Type: Supplementary protector
• Number of poles: Two-pole
• Terminals: Standard
• Type: UL 1077 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 1 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 15 kAIC
• Trip Type: 5-10X /n
• Application: Suitable for applications where medium levels of inrush current are expected
• Mounting Type: DIN Rail Mount
• Voltage Rating: 240 V
• Actuator Type: Toggle
• Current Rating: 1 A
• Characteristic: C Curve
• Enclosure Type: IP20
• Material: Nylon
• Temperature Rating: -40 to 75 deg C
• Wire Size: 18 to 6 AWG
