Eaton FAZ-C1/2-NA Branch Protector 1 A

Product Description

The Eaton FAZ-C1/2-NA branch protector is a UL 489 industrial miniature circuit breaker suitable for applications where medium levels of inrush current are expected. It has a 1A amperage rating and is designed with a C curve for circuit protection. It is a two-pole breaker with screw terminals.

• Suitable for applications where medium levels of inrush current are expected
• Current limiting design provides fast short-circuit interruption
• Easy installation on DIN rail

Product Highlights

The Eaton FAZ branch protector provides reliable circuit protection with a current limiting design and easy installation.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C1/2-NA

Technical Specifications

• Product Name: Eaton FAZ branch protector
• Catalog Number: FAZ-C1/2-NA
• EAN: 4015081020348
• Product Length/Depth: 1.4 in
• Product Height: 4.13 in
• Product Width: 2.97 in
• Certifications: UL 489 CSA Std. C22.2 No. 235
• Product Type: Branch protector
• Number of Poles: Two-pole
• Terminals: Screw
• Type: UL 489 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 1 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 10 kAIC 14 kAIC
• Trip Type: 5-10X /n
• Voltage rating: 277/480V
• Application: Suitable for applications where medium levels of inrush current are expected
• Actuator Type: Lever
• Enclosure Type: IP20
• Material: Nylon
• Mounting Type: DIN Rail
• Series: FAZ
• Temperature Rating: -40 to 75 deg C
• Wire Size: 18 to 6 AWG
• Voltage Rating - AC: 415 V
• Voltage Rating - DC: 96 V
• Packaging: Bulk
• Part Status: Active
• Illumination: None
• Breaker Type: Thermal Magnetic
• Approval Agency: ABS, CSA C22.2 No 5, UL489, VDE
• Moisture Sensitivity Level (MSL): Not Applicable
