Eaton FAZ-B20/1-SP Supplementary Protector, 240/415 VAC, 20 A, 1 Pole

Product Description

The Eaton FAZ-B20/1-SP is a supplementary protector with a current rating of twenty amperes. This UL1077 industrial miniature circuit breaker is designed for low levels of inrush current and provides reliable protection in various applications. It features a single pole configuration and operates at voltages of two hundred forty to four hundred fifteen volts.

• Rated for 20A and 15 kAIC
• Thermal magnetic trip with a 3-5X multiplier
• Compatible with standard terminals

Product Highlights

This product is ideal for applications such as control circuits, lighting, and supplementary protection. Its efficient design ensures superior protection for personnel and equipment within various electrical installations.

Product Information

Standard Information

• Brand: Eaton
• MPN: FAZ-B20/1-SP

Technical Specifications

• Voltage Rating: 240/415 VAC
• Amperage Rating: 20 A
• Number of Poles: 1
• Frequency Rating: 50-60 Hz
• Interrupt Rating: 15 kAIC
• Trip Type: 3-5X/B-Curve
• Material: Nylon
• Dimensions: 0.7 in W x 2.36 in D x 3.15 in H
• Mounting Type: DIN Rail
