Eaton EHD3030 C Series Type EHD Molded Case Circuit Breaker 480 VAC/250 VDC 30A

Product Description

The Eaton EHD3030 is a molded case circuit breaker designed for reliability and durability in electrical distribution applications. This breaker operates at 480 volts alternating current or 250 volts direct current with a current rating of thirty amps. It is built for use in panelboards, switchboards, and motor control centers. This product features a fixed thermal and fixed magnetic trip mechanism for enhanced protection.

• Three poles with a compact design.
• Rated interrupt capacity of fourteen kiloamperes at 480 VAC and eighteen kiloamperes at 240 VAC.
• Compatible with wire sizes ranging from fourteen to one-aught American Wire Gauge.

Product Highlights

This Eaton breaker provides efficient circuit protection and is suitable for various electrical assemblies and applications. It meets North American standards, ensuring dependable performance.

Product Information

Standard Information

• Brand: Eaton
• MPN: EHD3030

Technical Specifications

• Type: Type EHD
• Frame Size: F
• Phase: Three
• Voltage Rating: 480 VAC / 250 VDC
• Amperage Rating: 30 A
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 14 kAIC at 480 VAC / 18 kAIC at 240 VAC
• Dimensions: 3.38 x 4.13 x 6 inches
• Temperature Rating: 40 degrees Celsius
