Eaton E51PLP22 Limit Switch Inductive Proximity Sensor

Product Description

The Eaton E51PLP22 is a limit switch style modular sensor with versatile sensing solutions. It features five modes: thru-beam, reflex, polarized reflex, diffuse reflective, and fiber optic. This inductive proximity sensor has a right angle and operates with a 10-30 VDC input. It is suitable for industrial environments.

• Features a selector switch for light or dark operation
• Rugged construction ideal for industrial environments
• Components are interchangeable with E51 proximity sensors

Product Highlights

The Eaton E51PLP22 limit switch offers versatile sensing solutions with multiple modes and rugged construction for industrial use.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E51PLP22
• Country of Origin: US

Technical Specifications

• Product Name: Eaton E51 NEMA limit switch inductive proximity sensor
• Catalog Number: E51PLP22
• UPC: 782113208473
• Product Length/Depth: 1.54 in
• Product Height: 4.89 in
• Product Width: 1.82 in
• Product Weight: 0.975 lb
• Warranty: 3 year
• Compliances: CE Marked
• Certifications: UL Listed CSA Certified
• Product Type: Limit switch inductive proximity sensor
• Contact Rating: 600 mA
• Enclosure material: Receptacle and body: die cast zinc Head: plastic
• Operating mode: Diffuse reflective
• Connection: Screw terminal
• Contact configuration: Complementary PNP open collector
• Sensor type: Diffuse reflective
• Switch type: Photoelectric
• Input Voltage: 10-30 Vdc
• LED indicator: Lights when output is ON One red LED for each output
• Maximum DC current: 600 mA
• Operating temperature - max: 158 °F
• Operating temperature - min: -13 °F
• Environmental rating: NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67
• Alternate Mfr Part Number: E51PLP22
• Brand: Eaton - Cutler Hammer
• Manufacturer Part Number: E51PLP22
• Overview: LIMIT SWITCH
• Item: Proximity Sensor
• Height (cm): 12.42
• Length (cm): 3.91
• Width (cm): 4.62
• Country Of Origin: US
• Weight (kg): 0.4388
• (Instrument-Sensor) NEMA Protection: NEMA 3S
• (Instrument-Sensor) Connection Type: Screw Terminal
• (Instrument-Sensor) IP Protection: IP67
• (Instrument-Sensor) Type of Operator: PNP
• Manufacturer: Eaton
• (Instrument-Sensor) Temperature Range: -13 °F - 158 °F
• (Instrument-Sensor) Supply Voltage: 10-30 VDC
• (Instrument-Sensor) Type: Diffuse Reflective
• (Instrument-Sensor) Enclosure Composition: Body: Die Cast Zinc
• (Instrument-Sensor) Indication: One Red LED For Each Output
• Pricing Unit: Each
• Tariff code: 85365080
• Generic code: EAUS
