Eaton E50DN1 Lever Type Limit Switch Actuator

Product Description

The EATON E50DN1 is a lever-type actuator head designed for use with E50 series limit switches. It attaches to the E50 switch body and converts mechanical contact or cam motion into an electrical switching signal. This component is installed by licensed electricians and industrial maintenance technicians in control panel, conveyor, and machinery applications where precise position sensing is required. The lever-type design allows the actuator to respond to linear or rotary mechanical inputs, making it a reliable choice for machine guarding, end-of-travel detection, and automated process control systems.

This actuator head is suited for use in industrial and commercial settings where E50 series limit switches are deployed. Typical installations include conveyor systems, packaging machinery, material handling equipment, and automated assembly lines. It is designed to mount directly onto the E50 switch body, making it a direct-fit replacement or upgrade component for existing E50 installations. Electricians and automation technicians working under NEC guidelines will find this actuator straightforward to integrate into standard control circuits.

Key Features

• Lever-type actuator head for mechanical position sensing applications
• Compatible with E50 series limit switch bodies
• Compact form factor at 6.000 inches x 6.000 inches x 1.750 inches
• Lightweight construction at 0.5 pounds for easy handling and installation
• Designed for industrial control, conveyor, and machinery applications

Compatibility

Designed for use with EATON E50 series limit switch bodies as a lever-type actuator head replacement or component assembly.

Installation Notes

Installation should be performed by a qualified electrician or industrial maintenance technician. Disconnect and lock out all power to the control circuit before removing or installing the actuator head. Verify that the lever travel and actuation angle align with the mechanical cam or contact surface before securing the assembly. Follow all applicable NEC requirements for industrial control wiring and enclosure ratings.

Technical Specifications

• Actuator Type: Lever Type
• Length: 6.000 inches
• Width: 6.000 inches
• Height: 1.750 inches
• Weight: 0.5 pounds
• UPC: 78211330889

Standard Information

• Brand: EATON
• Manufacturer Part Number: E50DN1
