Eaton E47BLS05 ETN E47 Limit Switch 15A at 250 Vac 6A at 30 Vdc

Product Description

The Eaton E47BLS05 is a limit switch designed for precision control in automation systems. This enclosed precision limit switch features a plunger actuator and screw terminals. It operates at currents of 15 Amps at 250 VAC and 6 Amps at 30 VDC. The switch functions effectively in conditions with speeds ranging from 0.01 millimeters per second to one meter per second.

• Current rating: 15A at 250V AC, 6A at 30V DC
• Operating temperature range: -13 to 176 degrees Fahrenheit
• Actuator style: Plunger with screw terminal connection

Product Highlights

This switch is suitable for safety and security systems within industrial facilities. Its design includes a rugged aluminum enclosure for high durability.

Product Information

Standard Information

• Brand: Eaton
• Catalog Number: E47BLS05

Technical Specifications

• Connection Type: Screw Terminal
• Contact Configuration: 1-SPDT (Form C)
• Material: Aluminum
• Weight: 0.47 lb
• Height: 2.55 inches
• Length: 3.39 inches
