Eaton E30KB100 Molded Acetal Resin Push Button

Product Description

The EATON E30KB100 is a molded acetal resin push button operator designed for use in industrial control stations and panel-mounted switch assemblies. Acetal resin construction provides resistance to oils, solvents, and general shop-floor contaminants, making this operator a durable choice in demanding environments. Electricians and industrial controls technicians install this type of component when building or servicing operator interface enclosures, control panels, and machine start/stop stations. The E30KB100 fits into the E30 series mounting footprint and serves as the actuator portion of a complete push button assembly.

This operator is suited for light industrial, commercial, and facility maintenance applications where a reliable panel-mount push button actuator is required. Typical installations include motor control stations, conveyor line controls, HVAC unit control panels, and general-purpose start/stop circuits. It is intended for use by licensed electricians or qualified industrial controls technicians performing panel construction or field service work.

Key Features

• Molded acetal resin body resists oils, solvents, and common industrial contaminants
• Part of the EATON E30 series push button operator platform
• Designed for panel-mount installation in control enclosures and operator stations
• Actuator-style operator suitable for standard start/stop and momentary control circuits

Compatibility

Designed as an OEM-style operator for use within the EATON E30 series push button and control station platform. No additional specific compatible model numbers were provided in the product data.

Installation Notes

Installation should be performed by a licensed electrician or qualified controls technician in accordance with NEC requirements. De-energize and lock out the control panel before removing or installing any operator or contact block. Verify that the mounting cutout dimensions match the E30 series specification before installation. Do not over-torque the mounting hardware, as acetal resin components can crack under excessive clamping force.

Technical Specifications

• Material: Molded Acetal Resin
• UPC: 78211321553

Standard Information

• Brand: EATON
• Manufacturer Part Number: E30KB100
