Eaton E30JX1 Pushbutton Operator 6VAC/DC

Product Description

The EATON E30JX1 is a pushbutton operator with dual indicating lights and a 6VAC/DC light unit. It is designed for use in various industrial applications.

• 30.5 mm square multifunction design
• Illuminated with dual indicating lights
• Momentary operation for both top and bottom buttons

Product Highlights

This EATON pushbutton operator is ideal for applications requiring illuminated indication and momentary operation.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: E30JX1
• Country of Origin: US

Technical Specifications

• Mfr. #: E30JX1
• Mouser #: 504-E30JX1
• Type: 30.5 mm, Square Multifunction
• Size: 30.5mm
• NEMA: 3, 3R, 4, 12, 13
• Number of Buttons: 2
• Button Style: E
• Operation: Momentary
• Number of Lights: 2
• Lens Style: K
• Lamp Power Source: Full Voltage, 6VAC/DC
• Lamp Type: Incandescent
• Lamp Number: 6PSB
• Item: Pushbutton Operator
• Actuator Type: Two button, dual indicating lights
• Illumination: Illuminated
• Led Lamp Number: 6PSB
• Light Unit Type: Incandescent, Full Voltage
• Light Unit Voltage: 6V AC/DC
• Nema Enclosure Rating: NEMA 3 NEMA 12 NEMA 4 NEMA 13 NEMA 3R
• Notes: Light Unit Will Also Accept LED Lamp
• Operating Mode: Bottom: momentary Top: momentary
