Eaton e30ag E30 Series 30.5 Mm Two Button Operator

Product Description

The EATON e30ag is a non-illuminated, maintained-contact operator from the E30 Series, designed for use in industrial and commercial control panel applications. Built around a 30.5 mm mounting footprint, it features a square multifunction form factor with a two-button layout and a long OFF release bar. The maintained contact action holds its switched position after each actuation, making it well suited for applications that require a latching on or off state rather than momentary control. Licensed electricians and industrial controls technicians typically specify and install this operator.

The e30ag is intended for use in control stations, operator interface panels, and machine control enclosures where a robust, panel-mount pushbutton operator is required. Its NEMA 3, 3R, 4, 12, and 13 ratings make it appropriate for both indoor and outdoor installations exposed to dust, oil, and non-corrosive liquids. The top and bottom maintained configuration suits applications such as motor start-stop circuits, conveyor controls, and similar industrial switching tasks.

Key Features

• 30.5 mm panel cutout fits standard E30 Series mounting hardware
• Square multifunction form factor with two-button layout
• Long OFF release bar for reliable operator actuation
• Maintained contact action — holds position after actuation
• Non-illuminated design reduces wiring complexity
• NEMA 3, 3R, 4, 12, and 13 enclosure ratings for broad environmental suitability

Compatibility

Designed for use with the EATON E30 Series 30.5 mm operator platform. Consult EATON documentation to confirm compatible contact blocks and mounting accessories within the E30 Series lineup.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize the control circuit and lock out the panel before mounting or wiring the operator. The 30.5 mm panel cutout should be clean and deburred before inserting the operator body. Do not overtighten the mounting nut, as this may crack the operator housing or deform the panel.

Technical Specifications

• Series: E30
• Mounting Size: 30.5 mm
• Form Factor: Square Multifunction
• Actuation Type: Maintained (top and bottom)
• Button Configuration: Two button with long OFF release bar
• Illumination: Non-illuminated
• NEMA Rating: 3, 3R, 4, 12, 13

Standard Information

• Brand: EATON
• Manufacturer Part Number: e30ag
