Eaton E22DL24G Heavy Duty Pushbutton

Product Description

The EATON E22DL24G is a heavy duty pushbutton operator designed for industrial and commercial control panel applications. Pushbutton operators of this type serve as the interface between a machine operator and the control circuit, triggering start, stop, or function commands in hardwired control systems. The E22DL24G fits into the EATON E22 series 22 mm operator family, making it a direct-mount component for control station assemblies. Licensed electricians and industrial maintenance technicians are the primary installers and service personnel for this class of device.

This pushbutton is suited for use in commercial and industrial control enclosures where a durable, operator-accessible control interface is required. Typical applications include motor control stations, machinery panels, conveyors, and process equipment requiring reliable momentary or maintained operator input. The heavy duty construction makes it appropriate for demanding environments where frequent actuation or exposure to industrial conditions is expected.

Key Features

• Heavy duty construction for demanding industrial and commercial environments
• 22 mm mounting footprint consistent with the EATON E22 series operator platform
• Designed for integration into control station enclosures and panel assemblies
• Provides reliable operator interface for start, stop, or function control circuits

Compatibility

Designed as an OEM-style replacement or new-installation operator within the EATON E22 series 22 mm pushbutton platform, compatible with corresponding contact blocks and enclosures in that series.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the control panel before removing or installing any pushbutton operator. Verify the mounting hole diameter matches the 22 mm operator body before installation. Secure all contact block connections and confirm proper seating of the operator in the enclosure before restoring power.

Technical Specifications

• Weight: 1 pound
• UPC: 78211355234

Standard Information

• Brand: EATON
• Manufacturer Part Number: E22DL24G
