Eaton D5RR2T General-purpose relay DPDT 10A

Product Description

The Eaton D5RR2T is a general-purpose relay, also known as an ice cube relay, featuring a DPDT configuration and a 10A current rating. This relay is designed for quick and easy installation with minimal risk of damage. It is suitable for controlling smaller loads and applications requiring high current-carrying capacity.

• Flag indicator shows relay status in manual or powered condition.
• Push-to-test button allows manual operation without coil power.
• White plastic ID tag/write label for easy identification in multi-relay circuits.

Product Highlights

The Eaton D5RR2T general-purpose relay is ideal for various control circuit design applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D5RR2T

Technical Specifications

• Type: Ice Cube, Plain Cover
• Brand: Eaton
• Height: 1-1/2 Inch
• Length: 1-1/2 Inch
• Voltage: 300 Volt
• Amperage: 16 Amp at 120/277 VAC/28 VDC
• Material: Polycarbonate
• Resistance: 72 ?
• Power Rating: 1.4 W
• Mounting Type: DIN Rail/Panel/PCB
• Contact Rating: 10 A
• Number of Poles: 2 Pole
• Contact Material: Silver Alloy
• Operating Cycles: 5000000 Mechanical, 100000 Electrical
• Temperature Rating: -40 to 131 degrees F
• Dielectric Strength: 1500 VAC Between Coil and Contact, 1500 VAC Between Poles
• Contact Configuration: DPDT
• Environmental Conditions: -40 to 185 F Storage
• Catalog Number: D5RR2T
• Product Type: General-purpose relay
• Application: Commercial, Institutional Buildings and Structures Applications
• Relay Throws: Double Throw
• Relay Poles: Double Pole
• Component: Plug In Unit-Ice Cube Relay
• Relay Load Amperage: 10 Amp
• Coil Voltage Rating: 24 Volt
• Manufacturer: Eaton
• Coil Voltage: 24 VAC
• Mounting: Plug In
• Termination: Socket
• Nominal Coil Voltage: 24 VAC
• Current Rating: 10 A
