Eaton D3RR2T General-purpose relay ICE CUBE rl DPDT OCTAL BASE 10A 24VAC

Product Description

Eaton D3RR2T is a general-purpose relay designed for various applications, including controlling smaller loads and high current tasks. This relay is suitable for tight spaces due to its slim-form design, ensuring easy installation and secure operation.

• Solid construction with an octal base for reliability.
• Compatible with various coil voltages.
• DPDT contact configuration for versatile control options.

Product Highlights

The D series ice cube general-purpose relays deliver exceptional functionality across a wide range of control circuit designs, making them ideal for commercial and institutional applications.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: D3RR2T

Technical Specifications

• Amperage Rating: 16 A
• Coil Voltage: 24 VAC
• Contact Form: DPDT
• Contact Rating: 10 A
• Dimensions: 2.2 in L x 1.37 in W x 1.39 in H
• Enclosure: IP40
• Frequency Rating: 50/60 Hz
• Mounting Type: DIN Rail/Panel
• Number of Pins: 8
• Number of Poles: 2
• Temperature Rating: -40 to 131 deg F
• Standards/Approvals: UL Listed, cULus Recognized, CSA Certified, CE Marked
