Eaton D3RR2A General Purpose Relay, Ice Cube Relay, 10A, 120VAC Coil

Product Description

Eaton D3RR2A is a general-purpose relay designed for various applications. This ice cube relay operates with a coil voltage of 120 volts AC and features a double pole double throw (DPDT) contact configuration. It is suitable for controlling both small and large loads, making it versatile for different circuit designs.

• Compact design for installation in tight spaces
• Supports various load types up to 10 amps
• Compatible with DIN rail or panel mounting

Product Highlights

The Eaton D3RR2A provides reliable performance in commercial and industrial applications. It includes features for easy installation and is UL listed for safety compliance.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: D3RR2A

Technical Specifications

• Coil Voltage: 120 VAC
• Contact Configuration: DPDT
• Contact Current Rating: 10 Amps
• Number of Pins: 8
• Mounting Type: DIN Rail/Panel
• Amperage Rating: 16 Amps
• Temperature Rating: -40 to 131 degrees Fahrenheit
• Enclosure Rating: IP40
