Eaton D2PA7 Pilot Light Actuator

Product Description

The EATON D2PA7 is a pilot light actuator designed for use with the D2PR4 and D2PF4 series pushbutton operator assemblies. It combines an actuator mechanism with an integrated pilot light function, allowing operators to both initiate a control action and indicate status at the same panel position. Electricians and control panel builders install this component when building or servicing industrial control stations, machine control panels, and operator interface assemblies. The unit is compact, measuring 2.2 inches long by 1.75 inches wide by 1.3 inches tall, and weighs approximately 0.11 pounds.

This actuator is suited for use in industrial and commercial control panel applications where pushbutton stations require a combined actuation and indication function. It is intended for installation into D2PR4 and D2PF4 series operator housings and fits standard 22 mm panel cutout assemblies in that product family. Typical use cases include machine tool controls, conveyor systems, and process equipment operator stations where panel space is limited and dual-function components are preferred.

Key Features

• Combined actuator and pilot light function in a single panel position
• Compatible with D2PR4 and D2PF4 series pushbutton operator assemblies
• Compact form factor: 2.2 x 1.75 x 1.3 inches
• Lightweight construction at 0.11 pounds
• Suited for industrial control panel and machine operator station applications

Compatibility

Designed for use with EATON D2PR4 and D2PF4 series pushbutton operator assemblies.

Installation Notes

Installation is performed by a licensed electrician or qualified control panel technician. De-energize and lock out the control panel per NFPA 70E procedures before servicing or installing this actuator. Verify that the operator housing series matches the D2PR4 or D2PF4 series before installation. Consult the applicable NEC requirements and equipment documentation for wiring and panel construction standards.

Technical Specifications

• Dimensions (L x W x H): 2.2 x 1.75 x 1.3 inches
• Weight: 0.11 pounds
• UPC: 78668510731

Standard Information

• Brand: EATON
• Manufacturer Part Number: D2PA7
