Eaton D1RF1T1 General-purpose relay 24VDC

Product Description

The EATON D1RF1T1 is a general-purpose relay designed for various applications. This ice cube relay features a SPDT configuration and a 24VDC coil, capable of handling 15A. It is suitable for switching starting coils, heating elements, pilot lights, and audible alarms. Commonly used in dishwashers, fridges, and industrial assembly lines.

• SPDT contact configuration
• 24VDC coil voltage
• Contact rating of 15A

Product Highlights

The EATON D1RF1T1 relay is ideal for electrical assemblies, panels, and OEM applications, providing reliable switching for various control circuits.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D1RF1T1

Technical Specifications

• Product Name: Eaton General-purpose relay
• Catalog Number: D1RF1T1
• UPC: 786685930725
• Product Length/Depth: 2 in
• Product Height: 1 in
• Product Width: 1 in
• Compliances: RoHS Compliant CE Marked
• Certifications: UL Listed
• Product Type: General-purpose relay
• Type: Full Featured Ice Cube
• Volts DC Control: 24
• Base: 5-Blade
• Mounting: DIN Rail/Panel
• Poles: 1
• Amps: 15
• Approval: UL (Canada and Us), CSA, CE
• Application: General Purpose, Electrical Assemblies, Panels and OEMs Applications
• Coil Voltage: 24
• Power Rating: 1/2 hp, 1 hp
• Terminal Type: Plug-In
• Contact Rating: 15 A at 300 VAC
• Enclosure Type: IP40
• Temperature Rating: -40 to 185
• Contact Configuration: SPDT
• Contact Current Rating: 15 Amp
• Contact Voltage Rating: 300 Volt
• Series: D1 Series
• Dimensions: 2 in L x 1 in W x 1 in H
• Amperage Rating: 20
