Eaton D15CR62AB nema machine tool relay 110/120V

Product Description

The Eaton D15CR62AB NEMA machine tool relay is a Freedom 600V multi-pole relay with an eight-pole configuration. It features a 110/120V coil voltage and operates at 50/60 Hz. The relay has a 6NO-2NC contact configuration, with a 60A make and 6.0A break contact rating, and a 10A rated operational current. It is suitable for electrical assemblies, panels, and EOEMs applications.

• 600 VAC, 10 A continuous thermal current
• State indicator visually shows relay On or Off status
• Relay base has mounting holes on 35 x 60 mm centers, permitting direct replacement of competitive relays

Product Highlights

The Eaton D15CR62AB is a reliable multi-pole relay for various industrial applications, featuring easy installation and clear operational status indication.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: D15CR62AB
• Country of Origin: China

Technical Specifications

• Product Name: Eaton NEMA machine tool relay
• Catalog Number: D15CR62AB
• UPC: 782113807096
• Product Length/Depth: 4.66 in
• Product Height: 2.96 in
• Product Width: 1.8 in
• Certifications: CSA Certified UL Listed
• Product Type: Machine tool relay
• Type: Freedom 600V multi-pole
• Frequency rating: 50-60 Hz
• Number of Poles: Eight-pole
• Coil Voltage: 110/120 V
• Contact configuration: 6 NO-2 NC
• Contact Rating: 60 A Make/6 A Break
• Series: D15
• Application: Electrical Assemblies, Panels and EOEMs Applications
• Mounting Type: DIN Rail/Panel
• Terminal Type: Pressure Plate
• Enclosure Type: Open
• Dimensions: 4.66 in L x 1.8 in W x 2.96 in H
• Amperage Rating: 10
• Mounting Style: DIN Rail Mount
• Current Type: AC
• Packaging: Box
• Country of Origin: China
• Relay Poles: Eight Pole
• Relay Throws: Single Throw 6 Normally Open & 2 Normally Closed
• Relay Load Amperage: 10 Amp
• Coil Voltage Rating: 120 Volt
• Manufacturer: Eaton
• Relay UL Rating: CSA Certified
• Component: Machine Tool Relay
