Eaton Cutler-hammer ARC Relay Latch Attachment 600V

Product Description

The EATON CUTLER-HAMMER ARC is a relay latch attachment designed for use with AR series relays. This mechanical latch accessory converts a standard momentary-action relay into a latching relay, allowing the relay to hold its switched position without continuous coil energization. The result is maintained contact state even after control power is removed. Licensed electricians and control panel technicians typically source and install this type of attachment during panel builds, retrofit projects, or relay upgrades in industrial and commercial control circuits.

This latch attachment is rated for operation at up to 600 volts AC, making it suitable for a wide range of commercial and industrial control applications. It is intended specifically for use with AR series relays and is used in control panels, motor control centers, and similar low- to medium-voltage switching assemblies where latching relay function is required.

Key Features

• Converts AR series relays to latching operation without continuous coil power
• Rated for 600 VAC service
• Direct accessory fit for AR series relay bodies
• Compact attachment that does not significantly alter relay footprint
• Sold as an individual unit (package quantity of 1)

Compatibility

Designed for use with AR series relays as specified by EATON CUTLER-HAMMER. Confirm relay body style and mounting configuration before installation.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the control circuit before attaching or removing any relay accessory. Follow the relay manufacturer documentation for correct attachment orientation and engagement to avoid damaging the latch mechanism or relay body.
